Mean Well MDR-60-24 AC to DC DIN-Rail Power Supply 24 Volt 2.5 Amp 60 Watt
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| MPN | MDR-60-24 |
| Brand | MEAN WELL |
60W DIN-Rail switching Power Supply24 Volts @ 2.5 Amps Specifications Universal AC input rangeProtections: Short-circuit, Overload, Overvoltage 100% Full load burn-in test Soft-start circuit, limiting AC surge current Input Voltage: 85-264VAC @ 47-63Hz, or 120-370VDC Input Current @ Full load: 1.8A(115V) / 1.0A(230V) Size: 3.9" x 1.6" x 3.5" Weight: 0.7 lbs.3-year warranty Detailed specifications Primary Output Voltage (VDC): 24 Output Current (A): 2.5 Maximum Output Power (W): 60 Family: MDR-60 Input Voltage (VAC): 85 to 264 Input Frequency: 47 to 63 Maximum Input Current (A): 1.8 Output Connector Type: Screw Terminal Agency Approvals: UL/CUL/TUV/CB/CE/EN Efficiency (%): 88 Operating Temperature-Min (Cel): -20 Operating Temperature-Max (Cel): 70 Length (inch): 1.57 Width (inch): 3.54 Height (inch): 3.94 Color: White Style: DIN
