2pcs Mini360 3A DC Voltage Step Down Power Converter Buck Module 3.3V 5V 9V 12V
USD 2.50 USD
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Brand | Unbranded |
| Product Type | Power Converter |
| Conversion Direction | Step-Down |
| Switching Frequency | 340KHz |
| Country/Region Of Manufacture | China |
| Output Ripple | 30mV |
| Nominal Voltage Rating (AC) | 120 V |
| MPN | MINI360 |
| Nominal Current Rating | 3 A |
| Current Conversion | DC to DC |
| Color | Green |
| Nominal Power Rating | 120 W |
| Output Voltage Rating (DC) | 9 V |
| Nominal Voltage Rating (DC) | 12 V |
| Type | Forward Converter |
| Output Voltage Rating (AC) | 12 V |
| Inrush Current Rating | 3 A |
Specification: Model Name: Mini-360 Module Properties: non-isolated buck Rectification: synchronous rectification Input voltage: 4.75V-23V Output voltage: 1.0V-17V Output Current: lowering the value of 3A, long 1.8A Conversion efficiency: 96% (maximum) Switching Frequency: 340KHz Output ripple: 30mV (no-load) Load regulation: ± 0.5% Voltage regulation: ± 2.5% Working temperature: -40 Celsius to +85 Celsius Features: Use integrally molded power inductor and synchronous rectifier control chip, smaller and more efficient.
